ITG Universal Air Box ARAB65 Air Box with 60mm ID Filter
ITG Universal Air Box ARAB65 Air Box with 60mm ID Filter is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
ITG Universal Air Box ARAB65 Air Box with 60mm ID Filter
Description
Description
If your budget can't stretch to the RAB65 then this aluminium version of the same air box could be the answer. Originally designed to fit the Mk 1 Focus and the Mk 2 K Series engned Elise, this air box has been used by us on many other kits ranging from Renaults, MGs, Peugeots, Vauxhalls, etc.
A - (Length) Measurement taken from airbox inlet (C), to filter spinning outlet (D).
Rebated ARAB Spinning reduces length by approx. 20mm
B - (Width) Measurement taken at widest point of filter lid spinning.
Do not measure from screw to screw.
C - Inlet (Dirty air in) measurement taken as internal diameter.
See table for duct sizing guide.
D - Outlet (Clean air out) measurement taken as internal diameter, and relates to ARAB spinning used.
All dimensions are in mm
| Part No. | A (Length) | B (Width) | C (Inlet) | D (Outlet) | |
|---|---|---|---|---|---|
| ARAB65/58 | 353.00 | 164.00 | 99.00 | 61.00 | |
| ARAB65/60 | 374.00 | 164.00 | 99.00 | 63.00 | |
| ARAB65/63 | 372.00 | 164.00 | 99.00 | 66.00 | |
| ARAB65/67 | 374.00 | 164.00 | 99.00 | 70.00 | |
| ARAB65/67R | 346.00 | 164.00 | 99.00 | 70.00 | |
| ARAB65/70 | 376.00 | 164.00 | 99.00 | 73.00 | |
| ARAB65/73 | 372.00 | 164.00 | 99.00 | 76.00 | |
| ARAB65/73R | 347.00 | 164.00 | 99.00 | 70.00 | |
| ARAB65/78 | 365.00 | 164.00 | 99.00 | 81.00 | |
| ARAB65/84 | 367.00 | 164.00 | 99.00 | 81.00 |
